REFRIGERANT SYSTEM DIAGRAM
High Pressure
Switch
Accumulator
OUTDOOR UNIT
Pressure
Check Valve
Condenser
4-way
Valve
Muffler
Compressor
Expansion
Valve
Refrigerant Pipe
9.52mm (3/8")
Charging Valve
Evaporator
Charging
Valve
Refrigerant Pipe
15.88mm (5/8")
INDOOR UNIT
Strainer
Strainer
Strainer
: COOL
: HEAT
Models : AUH54LUAS / AOH54LJBYL
2006.01.27 4
