REL measurements.
If either calibration check produces a non-zero reading for 10 seconds, and the
meter is still under warranty, call General's Customer Service Department at
212-431-6100 to arrange to return the meter for service or replacement.
SPECIFICATIONS
Measurement Ranges 6.0 to 87.6% WME and 0.1 to 99.9 REL
Measurement Accuracy ±3% in pin mode
Length of Test Pins 10mm (0.4 in.) on remote probe; 10mm and 15mm
(spares)
Length of Remote Probe Cable 46 in. (1.168m)
Measurement Depth (pinless mode) 4 in. (102mm)
LCD Range/Size 6.0 to 87.6 count with 0.9 in. (23mm) high digits
LCD Resolution 0.1%
Bar Graph Composition 40 LEDs of 3 colors: green (0 to17%), yellow
(17 to 30%) and red (>30%)
Bar Graph Resolution ±1 LED (±2.5%)
Auto Power Off After 3, 5 or 10 minutes (user selectable) with
0% reading
Low Battery Warning Level <6.5VDC
Current Consumption <70mADC
Operating Temperature 32° to 122°F (0° to 50°C) @<80% relative humidity
Dimensions 9 x 2.75 x 1.625 in. (229 x 70 x 41mm)
Weight 8 oz. (249g)
Power Source 9V battery (included)
MAINTENANCE TIPS
When the icon appears at the upper left of the LCD, it’s time to replace
the 9V battery (although measurements will remain valid for hours afterwards.)
When the tips of the remote probe’s 10mm test pins show signs of wear,
replace them with a pair of 10mm or 15mm pins included in the case.
Remove the battery when storing the meter for an extended period of time.
Never drop or disassemble the meter or immerse it in water.
