3
PRODUCT
OVERVIEW
Fig. 1 shows the controls,
indicators and physical
features of the PNG1.
Familiarize yourself with
their locations before
moving on to the Setup
Instructions and
Operating Instructions.
1. Sensor
2. Red high alarm LED
3. Yellow low alarm LED
4. Green power on LED
5. Power button
6. Wrist strap
7. Battery compartment cover
SETUP INSTRUCTIONS
INSTALL BATTERIES
1. Open the PNG1’s battery compartment by
unscrewing the black cap at the base of the
instrument (Fig. 1, Callout 7).
7.
Fig. 1
1.
2.
3.
4.
5.
6.
PNG1 MANUAL_FINAL3_EFS_102114_ps 10/21/14 11:19 AM Page 3
