452013.06.20
INDOOR UNIT
COMPACT WALL MOUNTED
ASHG07LJCA
ASHG09LJCA
ASHG12LJCA
21
22 Joint Pipe Assy
Evaporator Total Assy
23
Holder (Room Thermistor)
Thermistor Assy
24
25 Evaporator Holder R
26
Filter Guide
Parts numberDescriptionRef
9317820011
9317838009
9317652001
9317651004
9317650014
9317649018
Rear Bracket
27
28
Evaporator Holder L
9316895003
9900563004
21
27
28
22
23
24
26
25
www.enindel.com
