2013.04.19 6
282 mm
185 mm
870 mm
INDOOR UNIT
COMPACT WALL MOUNTED
ASHG07LUCA
ASHG09LUCA
ASHG12LUCA
ASHG14LUCA
Drain hose length : 600 mm
INDOOR UNIT
COMPACT WALL MOUNTED
ASHG07LJCA
ASHG09LJCA
ASHG12LJCA
205 : Installed state
*1: Vertical flap is downward
203 mm
140 *1
10 *1
145 *1
790 mm
280 mm
INDOOR UNIT
COMPACT WALL MOUNTED
ASHG07LMCA
ASHG09LMCA
ASHG12LMCA
ASHG14LMCA
268 mm
15.8 to 16.7
203 mm840 mm
Drain hose
Diameter
Outside
Inside : 13.8 mm
600 mm
