INDOOR UNIT
COMPACT WALL MOUNTED
ASHG07LMCA
ASHG09LMCA
ASHG12LMCA
ASHG14LMCA
Evaporator
Fan
Fan Motor 9603269005
Crossflow Fan Assy 9316830004
Bearing C Assy 9306628017
35
32
Evaporator Total Assy (07, 09, 12)
933298900731
Evaporator Total Assy (14) 933298901431
Casing Assy 9333009001
33
34
Ref. Description Part number
552013.02.27
35
34
33
31
32
www.enindel.com
