GeneralAire 1042 Series User Manual

FORM NO. 1042-29 (FILE 10120) REV. B
Litho in U.S.A.
PARTS LIST FOR HUMIDIFIER
FILL OUT AND MAIL THIS
WARRANTY CARD AND
LITERATURE REQUEST FORM
A
IR
C
LEANERS AND
A
IR
P
URIFIERS
HUMIDIFIERS
D
IGITAL
H
UMIDITY
G
AGE
A
IR
F
ILTER
G
AGE
F
UEL
O
IL
F
ILTERS AND
A
CCESSORIES
GENERALAire
RESIDENTIAL AIR TREATMENT PRODUCTS
R
1099-9 THUMB NUT
1137-35 TROUGH COVER
1137-4 DISTRIBUTOR TROUGH
1042-5 DISTRIBUTOR TUBE
990-13 EVAPORATOR PAD
CABINET ASSEMBLY
1042-16 (24 V.)
P-103 COMPRESSION NUT
P-104 COMPRESSION SLEEVE
P-111 CONNECTOR
SOLENOID VALVE ASSEMBLY
990-53 (24 V.)
990-37-76 ORIFICE & STRAINER
ASSEMBLY
990-16-76 ORIFICE FITTING
990-17 STRAINER SCREEN
990-18 STRAINER BODY
1137-3 DRAIN PAN
P-163 HOSE CLAMP
1099-16 DRAIN TUBE

GeneralAire 1042 Series Specifications

General

Capacity	18 Gallons per Day
Voltage	24V
Type	Flow-through
Coverage Area	Up to 3, 000 square feet
Mounting Location	HVAC Duct
Water Supply Connection	1/4 inch copper tubing
Drain Connection	1/2 inch drain hose
