Product Dimensions and Specifications
Model Length(max) Width(max) Height (max)
Regeneration Mode
Genesis 2 AIO
8.3” 8.75” 7.5”
Downflow
The valve dimensions are for reference only.
Connect Port Dimensions
Product Model Inlet Port Outlet Port Drain Port Base Riser Pipe
Genesis 2 AIO
1” NPT 1” NPT 3/4” NPT 2.5” 8NPSM 32 mm
Main Technical Parameters
Power Input 100-240VAC 50/60Hz
Power Output 12VDC @ 2A
Regeneration
Cycles
Sequence 1: Service → Backwash → Air Draw → Fast Rinse
Regeneration Mode
A-01 Meter Delay: Regeneration happens when the capacity reaches zero and the preset time of regeneration is
reached.
A-02 Meter Immediate: Regeneration happens when the capacity reaches zero.
A-03 Intelligent Meter Delay: The same delay function as A-01 but the capacity is determined by entering the total
Resin Capacity, Feed Water Hardness, and the Number of People in the household. The control valve automatically
calculates the gallons for regeneration.
A-04 Intelligent Meter Immediate: The same function as A-02 but the capacity is determined by entering the Total
Resin Capacity and Feed Water Hardness. The control valve automatically calculates the gallons for regeneration.
A-05 Remaining Compare: Compares current usage with previous 365 day daily usage to intelligently determine
when regeneration will occur. Regeneration starts at the set regeneration time.
A-06 Is Factory Default:- Do not change.
A-07 Filter Meter: Filter mode, regeneration occurs when the capacity reaches zero and the preset time for
regeneration is reached.
5
