Genius BRAIN 15 User Manual

BRAIN 15
ENGLISH
Guide for the installer
Pagina 16
Leaf 2 starts the closing phase.
Send an OPEN command to determine the start of the
decelerated part and wait until the closing mechanical
stop point is reached.
Leaf 1 starts the closing phase.
Send an OPEN command to determine the start of the
decelerated part and wait until the closing mechanical
stop point is reached.
When leaf 1 reaches the closing mechanical stop point,
the setup phase is completed. If it has been performed
correctly, LEDs LD4 and LD5 turn off. If this is not the
case, LEDs LD4 and LD5 flash and the setup procedure
must be repeated.
With the MANUAL SETUP procedure, the leaf delay
at closure is set by default. To change it, execute a
second level programming (see paragraph 6.3.4.).
Pause time and leaf delay values can be modified,
both at closure and at opening, by simply pro-
gramming the second level parameters, without
repeating the setup procedure.
6.3.3 PrOgrAMMINg Of ThE LOgIC
Repeatedly press the SW3 push-button to select one of the 7
programming logics available. The selected logic is signaled
by the LD7 LED. The number of blinkings corresponds to the
number of the selected logic:
Tab. 3 - Selection logic
Logic
N°
pressure
SW3
N°
blinkings
LD7
“A”
Automatic
1 1
“E”
Semi-automatic
2 2
“AP”
"Stepped" automatic
3 3
“EP”
"Stepped" semi-automatic
4 4
“A1”
Automatic 1
5 5
“b”
Semi-automatic “b”
6 6
“C”
Dead man
7 7
6.3.4. SECONd LEvEL PrOgrAMMINg
To enter the second level menu, keep the SW2 SPEED push-
button pressed for more the 2.5 seconds. The two SETUP LEDs
are permanently lit. In this mode, the SPEED push-button is
used to scroll the menus. The different menus are identified
by the number of blinkings.
The parameter value is set with the LOGIC push-button. The
menu is scrolled sequentially. Keep the SPEED push-button
pressed for 2.5 seconds to exit the second level menu.
10.
11.
12.
13.
14.
Tab. 4 - Programming features
Menu
Function
N° pressure
SW2
N° flashes
LD8 LD7
on
LD7 off
1
Wind-proof
facility
1 1 YES NO
2
Over pushing
stroke
2 2 SI NO
3 Soft-touch 3 3 SI NO
4
Preliminary
blinking
4 4 SI NO
5
Leaf opening
delay
5 5 SI NO
6
Leaf closing
delay
6 6
counting of
delayed leaf
—
7 Pause time 7 7
counting time
break
—
With menus 6 and 7, keep the LOGIC push-button
pressed until reaching the time to be set. The time
can be set between 0 and 4.25 minutes.
6.3.5. rETUrN TO dEfAULT SETTINg
Keep the SETUP push-button pressed to switch the
board ON.
The two SETUP LEDs are alternately lit ("level crossing"
mode).
The board resets the parameters.
Until the SETUP push-button is pressed, movements
are inhibited.
When the SETUP push-button is released, the two LD4
and LD5 LEDs blink.
The default configuration is reset and the new Setup
can be started.
6.3.6. dEfAULT PArAMETErS
Here the default parameters:
Wind-proof facility NO
Over pushing stroke NO
Soft-touch NO
Preliminary blinking NO
Leaf opening delay YES
Leaf closing delay 10 sec
Pause time 30 sec.
7.INSTALLATION OF BUS ACCESSORIES
This board is supplied with a BUS circuit enabling easy con-
nection of a high number of BUS accessories (e.g. up to 16
photocells pairs), appropriately programmed, using only two
cable without polarity.
Below we describe the addressing and memory storage of
the BUS photocells.
For other future accessories, refer to the specific instruc-
tions.
1.
2.
3.
4.
5.
6.
