732789_Quick_Rev.A 5 Brain 16
ENGLISH
5. WORK TIME LEARNING
During the learning procedure, the stop and safety devices are disabled.
Therefore, avoid any transit in the leaf movement area when carrying out the
operation.
At learning start , the first movement must be opening. Should the system close,
reverse the motor opening and closing phase.
You must always install mechanical opening and closing stops.
If there is only one leaf, you must in any case complete the entire sequence.
Once the leaf is completely open, send 5 Open A pulses until the leaf begins to
close, then resume the normal procedure for leaf 1.
1. Ensure that the leaves are closed.
2. Keep “F” pressed until leaf 1 starts opening, and LED DL7 begins to flash.
3. Using the OPEN A pulses (from the radio control or the key button) the following functions are
commanded:
• 1
st
OPEN A - Start of leaf 1 opening deceleration
• 2
nd
OPEN A - Stop during leaf 1 opening and start of leaf 2 opening movement at full speed.
• 3
rd
OPEN A - Leaf 2 opening deceleration
• 4
th
OPEN A - Stop during leaf 2 opening and immediate start of leaf 2 closing movement at full
speed.
• 5
th
OPEN A - Start of leaf 2 closing deceleration
• 6
th
OPEN A - Stop during leaf 2 closing and start of leaf 1 closing movement at full speed.
• 7
th
OPEN A - Start of leaf 1 closing deceleration
• 8
th
OPEN A - Stop of leaf 1 closing.
4. LED DL7 stops flashing and the gate is ready for normal operation.
5.
If you wish to eliminate deceleration in some phases, you must wait for the leaf
to reach the stop and send 2 consecutive Open A pulses (within 1 sec.).
During normal operation, if during the opening/closing phase the cycle is
interrupted more than once, the leaf will not reach the stop with deceleration. At
the first complete cycle without interruptions, the system will reach the stops
and carry out the programmed decelerations again.
6. TECHNICAL SPECIFICATIONS
Mains power supply (+6 % -10% ) 230 V~ 50/60 Hz
Power absorbed from mains 10 W
Max. load per motors 800 W+800W
Accessories power supply and max. accessories current 24V
"
max 500 mA
Operating ambient temperature (-20.......+55 ) °C
Opening/Closing time
Programmable using the “F” key
from 1 to 120 seconds
Integrated radio (Max 250 codify)
433 MHz frequency RC
BRAVO - ECHO system coding
(Total opening)
