COMPAS 24 - COMPAS 24C
ENGLISH
Guide for the installer
Page 5
Notes on reading the instruction
Read this installation manual to the full before you begin installing the product.
The symbol indicates notes that are important for the safety of persons and for the good condition of the automated system.
The symbol draws your attention to the notes on the characteristics and operation of the product.
CE DECLARATION OF CONFORMITY
Manufacturer: GENIUS S.p.A.
Address: Via Padre Elzi, 32 - 24050 - Grassobbio- Bergamo - ITALY
Declares that: Operator mod. COMPAS 24 - COMPAS 24 CCOMPAS 24 - COMPAS 24 C powered on 230V~
is built to be integrated into a machine or to be assembled with other machinery to create a machine under the provisions of Directive
2006/42/EC;
conforms to the essential safety requirements of the following EEC directives:
2006/95/EC Low Voltage directive.
2004/108/EC Electromagnetic Compatibility directive.
and also declares that it is prohibited to put into service the machinery until the machine in which it will be integrated or of which it will
become a component has been identified and declared as conforming to the conditions of Directive 2006/42/EEC and subsequent
modifications.
Grassobbio, December 30, 2009
Managing Director
D. Gianantoni
•
•
•
•
•
INDEX
IMPORTANT WARNINGS FOR THE INSTALLER page.6
1. COMPONENTS (Fig. 1) page.6
2. TECHNICAL SPECIFICATIONS page.6
3. ELECTRICAL CONNECTIONS (Fig. 4) page.6
4. INSTALLATION page.6
4.1. PRELIMINARY CHECKS page.6
4.2 INSTALLATION DIMENSIONS page.6
4.3. INSTALLING THE OPERATOR page.7
4.4. WIRING THE OPERATOR page.7
4.5. POSITIONING THE MECHANICAL STOPS page.7
5. AUTOMATED SYSTEM TEST page.7
6. MANUAL MODE OPERATION page.7
7. SPECIAL APPLICATIONS page.8
8. MAINTENANCE page.8
9. REPAIRS page.8
10. ACCESSORIES page.8
