Genius LYNX 06 - Logic D Condo

30
ENGLISH
Logic D Condo C=from 1 to 9 d=0 E=1 P=1
Automated
system status
Inputs
Open / Close Close Stop
Safety devices
y=0
Active only for closure
y=1
Active for closing and opening
Closed
Opens and re-closes after
pause time
No effect
No effect, if active it disables the
OPEN commands
No effect
It disables the
OPEN commands
Open in pause
Recharges pause time. If held down, it stops the count and
resumes counting at release.
Closes immediately Stops operation
O=0 At release, if pause time has elapsed, re-closes after 5
seconds.
If it receives a CLOSE command while the safety device is engaged, it saves the command and re-closes after 5 seconds at
release.
At release, if pause time has elapsed, re-closes after 5
seconds.
If it receives a CLOSE command while the safety device is engaged, it saves the command and re-closes after 5 seconds at
release.
O=1 Closes immediately at release, if pause time has elapsed, re-closes after 5
seconds
At closure
Reverses movement to
opening
No effect Stops operation
Reverses movement to
opening
Stops operation and reverses to
opening after release
At opening No effect No effect Stops operation No effect
Stops operation and restarts
after release
