Genius SP-HF1250A User Manual

Version: 1.0 Page 12/15
Subwoofer
Ref. No.
Description
RS Part No. Part No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
Badge, L34xW16.9xT1.8 AL
Cloth , 2104 BLACK
Frame 6.0MDF
Speaker 4''4Ω 20W
Speaker 1″8Ω15W
Wood-box, 9T MDF PVC F-517-3c
Female Button
Function PCBA , Volume
Heat sink, AL Silver
Screw BAΦ3.0x12 ,
zincification Black Color
Bracket L15*W10*T1.0
Screw M3x8 , zincification Black Color
Back Board 9.0MDF
Paper Tube IDΦ35*ODΦ39*70L
Screw BAΦ3.5x20,
zincification Black Color
Power Switch
Screw PAΦ3.0x10,
zincification Black Color
AL Board, Black Color
PCBA
Cable Fastner 4K-4
PCBA
IC ST TDA2030A
Nut whit flange M4,
zincification Black Color
Transformer,
230V 50HZ
Screw ,M4*16 zincification Black Color
Knob,HIPS Silver Color
Deco ring HIPS, black coler
Screw BAΦ3.0x12 ,
zincification Black Color
Rubber foot ,black color
Screw BAΦ3.5x16 ,
zincification Black Color
016800958
014700618
034610688
010402978
010403028
035201968
027400148
033003428
017300478
017903258
021000378
017903228
034903138
015501168
017903248
011000118
017903278
034201308
033003478
027405578
033003488
019300238
008901148
017903238
026900958
026300698
017903258
015103558
017903268
s
Guide
ervice
SP-HF1250A
Chapter 5. Part List
