Genius SW-2.1 850 User Manual

Service Guide SW-2.1 850
Version 1.0 Page 7 of 16
* Attention
Please follow the numbered sequence marked within parenthesis given in individual
Flow chat, in that this is the best-recommended sequence to rectify the problems.
1.2.1 Satellite L/R channels no sound
Problem
Analyzer and
Identify the Causes
Solutions
Satellite L/R channels no sound
Broken or short circuit
Check solder points on
PCB
Defective
IC101,C123,C124,
C132,C133,
Speaker cable dis-connect or
speaker damaged
Re-connected speaker cable
or replace defective speakers
Check and replace
defective IC or
components

Genius SW-2.1 850 Specifications

General

System Type	2.1 Speaker System
Signal-to-Noise Ratio	≥70 dB
Satellite Driver Size	2 inches
Controls	Volume, Bass
Input Impedance	10k ohm
Input Sensitivity	400 mV
Weight	2.5 kg
Input	3.5mm
Subwoofer Driver Size	4 inches
