9
GM6000iE
10
11
AC Breaker:
to block current.
3
RV30
3
Multifunction Digital Display Meter: Yellow light
means that the amount of oil is too low, red light
means that the machine overload, green light
means normal operation; Power display on the
left, oil level display on the right; Rolling display
mode, respectively display accumulative running
time, output voltage, frequency rolling display
mode.
Circuit Breake: A circuit breaker interrupts the
current when the whole circuit is overloaded.
AC 120V NEUTRAL FLOATING AC 120V NEUTRAL FLOATING
AC BREAKER
AC BREAKER
CIRCUIT BREAKER
ON
OFF
AC 120V/240V
NEUTRAL FLOATING
AC RESETCO ALARM ECO.SW.
DC 5V 1A/2.1A
SYSTEM FLOATING
11
2
10
4
CO Alarm LED: Flashing red light: dangerous levels
of carbon monoxide gas have built up leave
immediately until area has aired out. Move generator
to well-ventilated area before operation. Flashing
yellow light: carbon monoxide sensor malfunction.
Sensor needs service.
Engine Switch: Switch to ON to turn ON the fuel,
then hold down to start the generator.
generator
generator.
generator
generator.
