13
STARTING UP THE GENERATOR
Press the LOW IDLE switch to "OFF";
4.
Press the main switch to "ON";
5.
Select the Fuel:
a. Gasoline: Turn the fuel source switch to gasoline;
b. LPG:
1. Connect the LPG hose to the LPG tank;
2. Tighten the other end of the LPG hose to the generator intake;
3. Turn the fuel source switch to LPG.
3.
1. 2. 3.
Remove the load from all output ends;
1.
Connect battery line before first use:
1. Loosen the two bolts on the panel cover and remove the left panel cover;
2. Connect the positive and negative electrodes of the battery.
Tip: Connect the same color wires together, do not connect the wrong
positive and negative wires.
2.
