Owner’s Manual
15
Battery
To start generator with electric start you will need a battery (not included). You can use a 12v lawn
tractor battery with the following specifications: The dimensions are Wx7.5” Dx5” Hx7” (including
terminals). A rated cranking amperage of 200. Terminals are regular, not reversed. Note: Using a
battery not designed for this unit may void warranty. Also this generator can also be started with
the pull start.
Photos below demonstrate battery plate attachment.
1) Bolt on plate with M6X40 bolts as shown below.
2) Put the battery on the frame, have the battery assembled with the provided accessories
as shown.
Accessories
M6x40
M6 Nut
Battery
