GENTRON Pro2 - Parts Breakdown: Cylinder Head Assembly

7500W Generator
30
APA Part No.
Description
Part. No
A
APG3009-A-01-JD HEAD COVER COMP. BOLT JF340-A-01
APG3009-A-02-JD HEAD COVER WASHER COMP. JF340-A-02
APG3009-A-03-JD WASHER COVER PACKING JF340-A-03
APG3009-A-04-JD HEAD COVER COMP. JF340-A-04
APG3009-A-05-JD HEAD COVER PACKING JF340-A-05
APG3009-A-06-JD FLANGE BOLT (M1OX 80) JF340-A-06
APG3009-A-07-JD SPARK PLUG JF340-A-07
APG3009-A-08-JD EXHAUST PIPE STUD BOLT JF340-A-08B
APG3009-A-09-JD CYLINDER HEAD COMP. JF390A-09
APG3009-A-10-JD CARBURETOR STUD BOLT JF340-A-10B
APG3009-A-11-JD CYLINDER HEAD SEALING PAD JF390-A-11
APG3009-A-12-JD DOWEL PIN (P lox 12X20) JF340-A-12
Cylinder Head assy.
