GENTRON Pro2 - Parts Breakdown: Cylinder Barrel

7500W Generator
31
APA Part No. Description Part. No
B
APG3009-B-01-JD FLANGE BOLT (M6X 14) JF340-B-01
APG3009-B-02-JD OIL LEVEL SWITCH ASSY. JF240-B-02
APG3009-B-03-JD 0-RING (14mm) JF240-B-03
APG3009-B-04-JD FLANGE NUT (MIO) JF340-B-02
APG3705-B-05-JD CRANK CASE JF390-B-02
APG3009-B-06-JD BALL BEARING (6207) JF340-B-04
APG3009-B-07-JD WASHER( 4 8.3 x 1 17x1) JF340-B-05
APG3009-B-08-JD LOCK PIN (10 mm) JF340-B-06
APG3009-B-09-JD GOVERNOR ARM SHAFT JF340-B-07
APG3009-B-10-JD OIL SEAL ( 8 x P 14 x 5) JF340-B-08
APG3009-B-11-JD DRAIN PLUG WASHER (12mm) JF340-B-09
APG3009-B-12-JD DRAIN PLUG BOLT JF340-B-10
APG3009-B-13-JD OIL SEAL ( 35 x 452x 8) JF340-B-11
APG3009-B-14-JD OIL PROTECTOR JF340-B-12
APG3009-B-15-JD BALL BEARING (6202) JF340-B-13
Cylinder barrel
