GENTRON Pro2 - Parts Breakdown: Crankcase Cover System

7500W Generator
32
APA Part No.
Description
Part. No
C
APG3009-C-01-JD DUCT COVER JD5000-A-01
APG3009-C-02-JD FLANGE BOLT (M8 X 35) JD5000-A-02
APG3009-C-03-JD OIL SCALE JF340-C-03B
APG3009-C-04-JD OIL SCALE SEAL RING JF340-C-02
APG3009-C-05-JD OIL SEAL(35X 452X8) JF340-B-11
APG3009-C-06-JD FLANGE BOLT (M8X35) JF390-C-01
APG3009-C-07-JD CRANKCASE COVER JF340-C-04B
APG3009-C-08-JD GOVERNOR GEAR WASHER (6 mm) JF340-C-06
APG3009-C-09-JD GOVERNOR GEAR JF340-C-07
APG3009-C-10-JD SLIDER SHAFT JF340-C-05
APG3009-C.-11-JD SLIDER WASHER (6 mm) JF340-C-08
APG3009-C-42-JD GOVERNOR SLIDER JF340-C-09
APG3009-C-13-JD BALL BEARING (6202) JF340-B-13
APG3009-C-14-JD BALL BEARING (6207) JF340-B-04
APG3009-C-15-JD CRANKCASE COVER PAD JF340-C-10
APG3009-C-16-JD DOWEL PIN (8X 12) JF240-C-11
Crankcase cover system assy.
