GENTRON Pro2 - Page 36

7500W Generator
Recoil Starter Assy.
36
APA Part No.
Description
Part. No
G
APG3009-G-01-JD RECOIL STARTER ASSY. JF340-G-01
APG3009-G-02-JD SETTING SCREW JF340-G-02
APG3009-G-03-JD SPRING RETAINER JF340-G-03
APG3009-G-04-JD PLATEN SPRING JF340-G-04
APG3009-G-05-JD STARTER DETENT JF340-G-05
APG3009-G-06-JD DETENT SPRING JF340-G-06
APG3009-G-07-JD RECOIL STARTER REEL JF340-G-07
APG3009-G-08-JD START RETURN SPRING JF340-G-08
APG3009-G-09-JD RECOIL STARTER CASE COMP. JF340-G-09
APG3009-G-10-JD RECOIL STARTER ROPE JF340-G-10
APG3009-G-11-JD STARTER KNOB JF340-G-11
APG3009-G-12-JD FLANGE BOLT (M6X8) JF340-G-12
1
