GENTRON Pro2 - Parts Breakdown: Carburetor Assembly

7500W Generator
Carburetor Assy.
38
APA Part No.
Description
Part. No
I
APG3009-I-01-JD TUBE CLIP JD3800-B-01
APG3009-I-02-JD TUBE A JD3800-B-02
APG3009-I-03-JD TUBE B JD3800-B-03
APG3009-I-04-JD WIPE HARNESS CLIP JD3800-B-04
APG3009-I-05-JD DASHPOT CHECK VALVE JD3800-B-05
APG3009-I-06-JD MANUAL CHOKE STAY ASSY. JD3800-B-06
APG3009-I-07-JD CARBURETOR IRON GASKET JF340-I-05
APG3009-I-08-JD CARBURETOR ASSY. JF390-I-04B
APG3009-I-09-JD CARBURETOR PAPER GASKET JF340-I-03
APG3009-I-10-JD CARBURETOR INSULATING PLATE JF340-I-02B
APG3009-I-11-JD INTAKE PIPE GASKET JF340-I-01
