GENTRON Pro2 - Parts Breakdown: Control Assembly

7500W Generator
Control Assy.
42
APA Part No.
Description
Part. No
M
APG3009-M-01-JD CONTROL ASSY. JF340-M-01B
APG3009-M-02-JD CONTROL BASE COMP. JF340-M-02B
APG3009-M-03-JD CONTROL ADJUSTING SPRING JF340-M-03
APG3009-M-04-JD PAN SCREW (M5 X 34) JF340-M-04
APG3009-M-05-JD FLANGE BOLT (M6 X 14) JF340-M-05
APG3009-M-06-JD GOVERNOR SPRING JF340-M-06
APG3009-M-07-JD THROTTLE RETURN SPRING JF340-M-07
APG3009-M-08-JD GOVERNOR ROD JF340-M-08
APG3009-M-09-JD FLANGE NUT (M6) JF340-M-09
APG3009-M-10-JD GOVERNOR ARM BOLT (M6) JF340-M-10
APG3009-M-11-JD CONTROL ARM JF340-M-11
