GENTRON Pro2 - Generator Components Overview

7500W Generator
Generator
48
APA Part No.
Description
Part. No
S
APG3009-S-01-JD STATOR COVER JD6500-D-01
APG3009-S-02-JD STATORASSY. JD6500-D-02
APG3009-S-03-JD COOLING FAN JD6500-G-03
APG3009-S-04-JD BRUSH ASSY. JD3800-G-04
APG3009-S-05-JD TAPPING SCREW JD3800-G-05
APG3009-S-06-JD RR HOUSING JD3800-G-06
APG3009-S-07-JD PAN SCREW JD3800-G-07
APG3009-S-08-JD FLANGE BOLT (M6X 179) JD6500-G-08
APG3009-S-09-JD AUTO VOLTAGE REG. ASSY. JD6500-G-09
APG3009-S-10-JD GENERATOR COVER JD3800-G-10
APG3009-S-11-JD CABLE TIE JD3800-G-11
APG3009-S-12-JD FLANGE BOLT JD3800-G-12
APG3009-S-13-JD ROTOR COMP. JD6500-D-03
APG3009-S-14-JD BEARING ASSY. JD3800-G-14
APG3009-S-15-JD PLAIN WASHER JD3800-G-15
APG3009-S-16-JD FLANGE BOLT (M10) JD6500-D-04
APG3009-S-17-JD FLANGE BOLT (M5) JD6500-D-05
