GENTRON Pro2 - Parts Breakdown: Wheel & Hand Assembly

7500W Generator
Wheel & Hand Assy.
50
APA Part No.
Description
Part. No
T
APG3009-T-01-JD PIN SPLIT JD6500-T-01
APG3009-T-02-JD WSHER PLAIN JD6500-T-02
APG3009-T-03-JD WHEEL JD6500-T-03
APG3009-T-04-JD BAFFLE JD6500-T-04
APG3009-T-05-JD SHAFT JD6500-T-05
APG3009-T-06-JD FLANGE BOLT (M6X 35) JD6500-T-06
APG3009-T-07-JD FLANGE NUT (M6) JD6500-T-07
APG3009-T-08-JD VIBRATION ABSORBER JD6500-T-08
APG3009-T-09-JD FLANGE NUT (M8) JD6500-T-09
APG3009-T-10-JD FEET JD6500-T-10
APG3009-T-11-JD FLANGE BOLT (M6X 16) JD6500-T-11
APG3009-T-12-JD FLANGE NUT (M8) JD6500-T-12
APG3009-T-13-JD HAND JD6500-T-13
APG3009-T-14-JD FLANGE BOLT (M6X 60) JD6500-T-14
APG3009-T-15-JD BRACKET JD6500-T-15
APG3009-T-16-JD FLANGE BOLT (M8X 58) JD6500-T-16
APG3009-T-17-JD FLANGE BOLT (M8X 40) JD6500-T-17
