Button Function
ON/OFF
If the GNSS receiver is off:
Turns on the GNSS receiver when held for 2 s.
☞
While the Zenith16/40 is booting the two
Power LEDs flash.
If the GNSS receiver is already on:
Turns off the GNSS receiver when held for 2 s.
☞
All functions described assume the Zenith16/40 is already on.
Button Function
Function
Press and hold button for <1 s.
Switches the receiver between rover or base mode.
Press and hold button for 3 s.
Updates the base position coordinates when the GNSS
receiver is in base mode. The RTK base LED flashes
ON/OFF button
Function button
Instrument Components 10
en
