MASTERBOARD
I2C
connectors
Battery
I2C
connectors
RFID
module
ALTERA
600dpi
Motor X (carriage)
driver
Motor Y (paper) driver
Motor Z (GCB) driver
Paper encoder
TAG
(CON29)
Paper end
connector
4PH
Power supply
V+ = 30V
V- = GND
EARTH
N
L
Power
30V
GND
EARTH
Potentiometer
+V -V NL
32
I2C
connectors
ALTERA
600dpi
Motor X (carriage)
driver
Motor Y (paper) driver
Motor Z (Roll to Roll) driver
Power
RFID
module
I2C
connectors
Paper encoderCommon
