Gerber Technology GERBERplotter Infinity 45 User Manual

70 pages

To Next Page

Infinity 45-85

™

GERBERplotter

™

Getting Started Manual

Manual de Inicio

Default Chapter4
- Table of Contents4
Table of Contents6
Table of Illustrations6
Introduction7
Waste Electrical and Electronic Equipment (Weee)7
System Requirements8
Customer Support9
Safety Instructions10
- Safety Labels10
- Warnings and Cautions10
- Dangerous Procedures10
- Moving Machinery11
- Do Not Refill Ink Cartridges11
- Ink Hazards11
- Safe Removal of Bulk Ink Cartridge11
Operating the Infinity Gerberplotter12
- Basic Concepts12
System Description13
- Figure 1. Infinity Gerberplotter13
- Figure 2. Control Panel14
Getting Started Procedures At-A-Glance15
Hardware Installation16
- Inventory16
- Figure 3. Plotter Shipping Container Contents (Typical)16
- Unpack/Assemble17
- Figure 4. Back Panel Installation17
- Figure 5. Plotter Assembly18
- Figure 6. Nipbar Stop Installation20
- Leveling the Infinity21
- Figure 7. Plotter Leveling21
- Changing the Plotter Power Setting23
- Figure 8. Power Switch Setting23
- Figure 9. Infinity Serial Number Plate (Typical)24
- Connecting Cables to Rear of Plotter25
- Figure 10. Plotter Rear Connections25
- Bulk Ink Cartridge Installation26
- Powering up the Plotter26
- Figure 11. Installing the Bulk Ink Cartridge26
Software Installation27
- Figure 12. Infinity Installation Screen27
- Figure 13. Winplot Warning Dialog Box28
Communications Setup29
- Serial Use Setup - Infinity 45 and Infinity 8529
- Network Use Setup - Infinity 8529
- Plotter Setup29
- Network Setup Interface30
- Figure 14. Infinity Network Setup Interface31
Long-Life Ink Delivery System - Infinity 8532
- Description32
- Figure 15. Long Life Ink Delivery System32
- System Priming33
- Figure 16. Priming Tool33
- Figure 17. Disengage CPC Connector from Mounting Clip33
- Figure 18. Connecting Primer to CPC Connector34
- Print Head Cartridge Installation35
- Figure 19. Infinity Print Head Cartridge and Tube Assembly35
- Figure 20. Print Head Cartridge Assembly36
- Figure 21. Inkjet Cartridge Installation36
Inkjet Cartridge Installation - Infinity 4538
Paper Installation39
- Paper Supply Roll39
- Figure 22. Paper Supply Roll Installation39
- Paper Path40
- Figure 23. Paper Path40
- Paper Take-Up Roll41
- Figure 24. Paper Take-Up Roll Installation42
- Figure 25. Nipbar Arm Engagement43
- Figure 26. Supply Paper Taped to Take-Up Roll44
- Figure 27. Wrapping Supply Paper Around Introduction45
Calibration46
- Inkjet Cartridge Alignment46
- Figure 28. Plotter Calibration Screen46
- Figure 29. Inkjet Cartridge Alignment Test47
- Plot Length Calibration48
Test Plot49
- Figure 30. Plotter Icon49
- Figure 31. Winplot Screen50
- Figure 32. Choose Files to Plot Screen50
- Figure 33. Winplot Screen51
Infinity User Interface Guide52
- Figure 34. Infinity Plotter Status Screen52
  - Accessing Screens53
  - Figure 35. Infinity User Interface Toolbar53
Bulk Cartridge Parameters55
- Figure 36. Bulk Cartridge Parameters55
Paper Monitoring Parameters57
- Figure 37. Paper Monitoring Parameters57
Communications Baud Rate59
- Site Requirements60
- Technical Specifications60
- Print Engine60
- Host Connectivity60
- Paper60
- Floor Space Requirements60
- Weight60
- Power Requirements60
- Using the Hp 51645A Inkjet Cartridge for Infinity 8561
- Troubleshooting62
- Printing Troubleshooting62
- Error Handling Process Flow64
- Error Codes - Infinity 8565
- Trouble Communicating over the Network66
- Figure 38. Serial Settings66
- Figure 39. Connection Settings67
- Consumables68

Questions and Answers:

S
Sydney CarterJul 26, 2025
Why is my Gerber Technology Plotter printing blank pages?
- P
  Philip FieldsJul 26, 2025
  If your Gerber Technology Plotter appears to be printing, but the media is blank, it might be due to several reasons. First, check if the tape covering the nozzles of the ink jet cartridge (Infinity 45) or the Infinity 85 print head cartridge was not removed. In this case, temporarily remove the ink jet or print head cartridge and remove/discard the tape. Another possible cause is that the Infinity 45 ink jet cartridge or Infinity 85 bulk ink cartridge is out of ink. To solve this, install a new ink jet or bulk ink cartridge.
D
Daniel PittmanAug 8, 2025
What to do if print is faded on Gerber Technology Plotter?
- M
  Marilyn DavisAug 8, 2025
  If the print from your Gerber Technology Plotter is faded, it could be due to a few reasons. The Infinity 45 ink jet cartridge or Infinity 85 print head cartridge might be low on ink. In this case, install a new ink jet cartridge or a new bulk ink cartridge. Additionally, the Infinity 45 ink jet cartridge or Infinity 85 print head cartridge could be clogged. Try removing the ink jet cartridge or print head cartridge and cleaning it with a clean, lint-free cloth moistened with de-ionized water.

Gerber Technology GERBERplotter Infinity 45 Specifications

General

Category	Plotter
Max Cutting Width	114.3 cm (45 in)
Maximum Plot Width	114.3 cm (45 in)
Media Types	Paper, Mylar
Interface	RS-232
Model	GERBERplotter Infinity 45
