Gerber Technology MP+ Series User Manual

54
FLOW CHART
1.
Visually check damaged
pad connector and
clean contact pads.
2.
Swap cartridge with
a working one.
3.
Reconnect all at cables.
4.
Cross small at cables
on the carriage board
Between the OK and
the wrong one
5.
Place small at cables to
the original position.
6.
Cross long at cables
CON9 - CON10 on
master board.
Replace
Damaged
pad connector
Error moves
with the cartridge
Error moves to
the OK one
Error still
on OK one
Error still
on wrong one
Error solved
Replace
cartridge
Replace
cables
Replace
small at
cable
Replace
cartridge
control board
Replace
master
board
Replace
carriage
board
Replace long at cables
CON8,CON9,CON10
and put them on original position
Error not anymore on wrong one
Error on wrong one
Error moves to PH2
Error persist
Error persist
Error on the same printhead
