GESTRA BK 15 - Page 22

22
Flange CL150
p Pressure
1
barg
19.6
13.8
10.2
8.4
6.5
5.5
T Temperature
1
°C
–29 — 38
200
300
350
400
425
∆ PMX Max. admissible
differential pressure
barg 19.6
p Pressure
1
psig
285
260
200
140
110
80
T Temperature
1
°F
–20 — 100
200
400
600
700
800
∆ PMX Max. admissible
differential pressure
psig
284
1
Ratings for strength of body/cover to ASME B16.5
Flange CL300, screwed socket G, screwed socket NPT, socket-weld end EN/ASME CL3000
p Pressure
1
barg
51.1
43.8
39.8
37.6
34.7
28.8
T Temperature
1
°C
–29 — 38
200
300
350
400
425
∆ PMX Max. admissible
differential pressure
barg
22
p Pressure
1
psig
740
680
635
570
530
410
T Temperature
1
°F
–20 — 100
200
400
600
700
800
∆ PMX Max. admissible
differential pressure
psig
319
1
Ratings for strength of body/cover to ASME B16.5
You can find precise information on the pressure and temperature ratings of your equipment on the name
plate and in the data sheet.
