GESTRA UNA 38 - Description; Scope of Supply and Equipment Specification

6
Description
Scope of supply and equipment
specification
Scope of supply
Our equipment is delivered packed and ready for
assembly.
Equipment specification
UNA 38
No.
Designation
1
Hex nuts
2
Sleeves
3
Body
4
Body gasket
5
Set screws
6
Bimetallic vent
7
SIMPLEX control unit
8
DUPLEX control unit
No.
Designation
9
Cover
10
Rating plate
11
Drain with screw plug
12
SIMPLEX AO 80 MAX control unit
13
DUPLEX AO 80 MAX control unit
14
Direction of flow arrow
