32
DIMENSIONS
TECHNICAL DATA
Rated voltage Vn: 230Vac phase/neutral TT and TN
Operating voltage: from 0.85 to 1.1 Vn
Power absorbed at rest: 8 VA
Power absorbed in the blocked state: 8 VA
Rated current: - 25A GW 90 901
- 40A GW 90 902
Maximum test duration: 2 minutes
Insulation voltage towards earth: 2500V
Pure differential switch sensitivity: 30 mA
Type: A
Number of DIN modules: 5
Number of Poles: 2
Use temperature: from - 5°C to + 40°C
Auxiliary contact
- Rated voltage: 230Vac
- Max. current: 50mA cos ϕ =1
- Min. current: 0.6mA
- Terminal cross-section: ≤ 2.5mm
2
