GEYA GRT8-FR - Adjustment of the Product; Fast Adjustment of Delay Time; Delay Function Setting; Examples

http://www.geya.net
Disposal of Electrical Waste
All electrical waste should be
disposed of in compliance with
current WEEE regulations.
Caution
The products must be installed by qualified electricians. All and
any electrical connections of the time relay shall comply with
the appropriate safety standards.
Examples
Dimensions(mm)
-2-
95
4.2
MD
GRT8-FR
R
252628
3
~
M
K
L1L2
L3
M2
QS
FU
K
M2
K
M1
K
M2
K
M1
K
A1
K
15
18
28
STP
ST
K
A1
GRT8-FR
L
N
A1
A2
25
KK
M1
MH
D
0.1M 0.1H
0.1S
MH
D
0.1M 0.1H
0.1S
0.1D
S
0.1D
S
MH
D
0.1M 0.1H
0.1S
0.1D
S
Running state
Running state
Short press to enter the delay
time setting
Delay time t1 setting
Short press to adjust the parameter
value, long press to realize rapid
adjustment (when the value exceeds
99, it will start from 0)
Delay time t2 setting
Short press to adjust the parameter
value, long press to realize rapid
adjustment (when the value exceeds
99, it will start from 0)
Delay time t3 setting
Short press to adjust the parameter
value, long press to realize rapid
adjustment (when the value exceeds
99, it will start from 0)
Adjustment of the product
Fast adjustment of delay timeDelay function setting
Press and hold for 3 seconds to enter / exit
the function setting
Set range：
t1 delay time base setting
Set range：
t2 delay time base setting
Set range：
t1 delay time base setting
Positive timing
Count down
Set timing display mode
Set range：
NOTE:
Short press to adjust the parameter value, long press to
realize rapid adjustment, if there is no operation key within
60 seconds, it will automatically exit the setting mode. In
the setting mode,You can press and hold the key for 3
seconds to exit and save the settings。
NOTE:
Short press to adjust the parameter value, long press to
realize rapid adjustment, if there is no operation key within
60 seconds, it will automatically exit the setting mode.
