1002 - 1013 Wasserbäder
Water Baths
The upper hose connection of the water level regulator is the water supply. Connect this to
the tap a laboratory hose (inside diameter max. 9 mm). The lower hose connection is for
water outlet and must be connected to a lower placed drain. Make sure that the water flows
off without being dammed up.
All hose connections must be secured with hose clamps.
The required water level can be adjusted with the outlet tube of the level regulator. To do so,
loosen the outlet tube screwing with a spanner GW 27. The water level can now be set by
pulling out or pushing in the tube. Tighten screwing again. Now carefully open water tap and
fill Water Bath with water as described in article 4.
6. Starting Operation
Switch on main switch. The green pilot lamp will glow.
7. Temperature Regulation
After switching on the Water Bath, the display shows the actual inside basin temperature. By
pressing key "°C", the display will show the last set and registered temperature that will now
be used again automatically.
The temperature range is between approx. 5°C above ambient to 99.9°C, temperature
constancy (temporal) approx. +/- 0.1°C. The set temperature can be changed with keys "°C",
"+" and/or "-". By pressing key "°C", the display switches from actual to set temperature. By
pressing key "°C" and either "+" and/or "-" simultaneously (two finger operation), the required
temperature can be set in 0.1°C steps. The counting speed increases after a short time. The
new set temperature is saved as soon as key "°C" is released. The display will now show the
actual temperature again.
The yellow pilot lamp next to the temperature display shows that heating is in operation.
CAUTION:
Hot surfaces when temperatures
rise above 60°C .
Do not touch!
Danger of burns!
Seite 11 Rev.03
