Schüttelapparate - Shakers
3005 / 3006 / 3011 / 3013 / 3015 / 3016 / 3019 / 3023
Seite 11 Rev5 vom /dated 27.10.2014
7. Technical data
Exterior dims. (wxdxh)
Model 3005
380 x 510 x 140mm / 330 x 330mm
Shaking platform (wxd)
Model 3006
380 x 510 x 140mm / 330 x 330mm
Model 3011
510 x 625 x 170mm / 450 x 450mm
Model 3013
510 x 625 x 170mm / 450 x 450mm
Model 3015
510 x 625 x 142mm / 450 x 450mm
Model 3016
510 x 625 x 145mm / 450 x 450mm
Model 3019
745 x 730 x 135mm*/ 676 x 540mm
Model 3023
380 x 510 x 125mm / 330 x 330mm
* dimension without suppert rod
Max. load
Models 3005 and 3006
to max. 8 kg
> depending on the kind of load
Models 3011, 3013, 3015, 3016
to max. 15 kg
(even load distribution) and the
Model 3019
to max. 30 kg
required shaking frequency
Model 3023
to max.1.2 kg
Motion /
Model 3005
orbital / 10mm / 20-500min
-1
Motion amplitude /
Model 3006
reciprocating / 20mm / 20-300min
-1
Motion frequency
Model 3011
three-dimensional orbital rocking /
3 degrees to horizontal /
2 – 50min
-1
Model 3013
rocking /
3 degrees to horizontal /
2 – 50min
-1
Model 3015
orbital / 30mm / 20-300min
-1
Model 3016
reciprocating / 30mm / 20-300min
-1
Model 3019
orbital / 32mm / 20-250min
-1
Model 3023
orbital / 3,0mm / 100-1450min
-1
Electrical connection
all models
115V or 230V, +/-10%, 50....60Hz
Mains fuse
all models, house mains
circuit protected by 10 Amp
Power
Model 3005
65W
Model 3006
65W
Models 3011 and 3013
90W
Models 3015, 3016 and 3023
65W
Model 3019
90W
Protection type/class
all models
I / IP20
Surrounding conditions
all models
Use only inside buildings
(not in explosion endangered surroundings)
Temperature
all models
+10°C to +50°C
Humidity
all models
max. 70% rel. humidity up to 31°C,
decreasing to 50% rel. humidity at
50°C, non-condensing.
Weight
Models 3005 and 3006
9.1kg
Model 3011
17.4kg
Model 3013
15.4kg
Models 3015 and 3016
16.8kg
Model 3019
32.7kg
Model 3023
12.5kg
