Installation Manual Series CF (excluding encapsulated screw compressors) 23042013 Rev. A / May 2007 2 of 60
Introduction
The purpose of this installation manual is to pro-
vide assistance when fitting the Series CF com-
pressor elements into compressor systems or
groups. All information and specifically data relat-
ing to safety contained in this manual should be
incorperated into the operating company’s opera-
tion manual.
Content of this installation manual is property of
GHH RAND. Reprint and reproduction are pro-
hibited without previous written consent from
GHH RAND.
The details of this installation manual do not enti-
tle to any claims concerning the specified GHH
RAND products. All warranties, other agreements
as well as terms and conditions are in confor-
mance with the general sales and delivery condi-
tions of GHH RAND copies available on request.
Service and maintenance is only permitted to
be carried out by a GHH RAND authorized
service bureau.
GHH RAND reserves the right to modify and im-
prove their products without advance notice.
GHH RAND is not obligated to do these modifica-
tions or improvements on already sold and deliv-
ered products subsequently.
This series is only constructed for operation un-
der following conditions and use:
„Air compression, not containing common or
perceptible added gases, vapours or impu-
rity“!
RNUNG
Operation of this compressor under conditions as
listed under chart 1
− is not permitted by GHH RAND,
− can impact on safety of the operator or other
persons and
− can interfere with warranty claims.
CHART 1
ISATZ
1)
directly aerated respiration for persons
2)
indirectly aerated respiration for persons
3)
operation of compressor in areas beyond
specified temperature range (see Annex 1
Technical data)
4)
operation of compressor in areas of con-
sisting or predictable risks caused by
flammable gases or vapours
THIS COMPRESSOR IS NOT BUILT FOR OP-
ERATION IN POTENTIALLY EXPLOSIVE AR-
EAS AND IS NOT ON ANY ACCOUNT PER-
MITTED TO BE USED IN THESE AREAS.
In case of utilization of spare parts not specified
in the GHH RAND spare parts list, GHH RAND
will not accept responsibilities for consequential
damages.
WARNING!
Utilisation of incorrect coolants can dam-
age rotary screw compressor stages.
We recommend the use of coolant
„PrimeCool“ or „PrimeCool Plus“.
Please contact GHH RAND for further in-
formation!
RECEPTION
The compressor has to be carefully inspected after
recept. Indications of careless handling on the part of
the freight carrier has to be noted upon receipt, par-
ticularly if the compressor will not be unpacked imme-
diately. A declaration of consent signed by the freight
carrier regarding damages detected will simplify the
processing of any subsequent insurance claims.
IMPORTANT INFORMATION
THE GOODS HAVE TO BE IMMEDIATELY
INSPECTED AFTER RECEPTION.
GHH RAND ARE ABSOLVED FROM RESPONSI-
BILITY FOR DAMAGE CAUSED IN SHIPMENT TO
THE GOODS AFTER SIGNATURE OF WAYBILL BY
FREIGHT CARRIER.
.
