8
ELECTRICAL WIRING:
The electrical wiring must be carried out as indicated in the drawing. Check that the supply voltage and the
frequency correspond to those indicated on the rating plate.
It is advisable to install a switch with fuses or a magnetothermal one.
After all the connections to make sure that the power cables are properly secured and protected from
shocks and from contact with hot and/or sharp surfaces.
CONNECTION OF AIR AND STEAM DISCHARGE:
It is advised to discharge the air suctioned by the working planes to the outside of the working place by connecting
a pipe to the suction blower outlet. This pipe must have suitable length and diameter in order not to alter equipment
working.
13 - TROUBLESHOOTING AND SOLVING
The following diagnostic table reports the main problems which might occur, their probable causes and possible
solutions. In case of doubts and/or unsolvable problems using this table, do not look for the malfunction by
dismantling the equipment or by proceeding by attempts, but contact the Technical Office or reseller.
ATTENTION: if the safety valves is released, switch the boiler immediately off and contact a qualified
technician. Do not block the exhaust and do not underestimate the problem, as there could be risk of
explosion.
14 - MAINTENANCE PROCEDURES
In case of irregularities or malfunctioning, please contact the service technician for the relevant checks.
Periodically, it is necessary to carry out the following operations:
This machine does not require special equipment for check and/or maintenance operations. It is however advisable
to use suitable tools and personal protections in compliance with the Italian law by decree 626/94, which have to be
in good conditions (Presidential Decree 547/55), in order to avoid any damages to persons or machine
components.
Make sure that the power and hidraulic supply are disconnected prior to any maintenance service
and that the whole equipment is cooled down.
15 - DISPOSAL
During the maintenance on the machine, or in case of its scrapping, please dispose carefully and correctly of any
polluting components, according to the local regulations. In case of scrapping, the identification rating plate and any
other document have to be destroyed.
PROBLEMS POSSIBLE CAUSES SOLUTIONS
Micro-switch of the pedal defect Replace the micro-switch
Malfunctioning motor or condenser Replace
Thermostat defect Replace the thermostat
Malfunctioning resistances Replace
Main switch not on Check if the main switch is on and the fuses.
Switch turned off Turn on the switch
Iron starting switches or heater de-
activated / Malfunctioning solenoid
valve
Turn the switch on/Check the solenoid valve.
The sounder is activated Lack of water / water too distilled Fill up the tank or do so using tap water
The pumps loads the heater too much Dirty probe Clean the heater probe
The machine doesn’t turn on
The boards do not heat up
