GHIDINI SIMBA Mini - Table of Contents; Introduction; General Description; Machine Identification

2
CONTENTS
1 INTRODUCTION
2 GENERAL DESCRIPTION
3 MACHINE IDENTIFICATION
4 TECHNICAL FEATURES
5 MACHINE COMPONENTS
6 MACHINE UNPACKING AND INSTALLATION
7 INSTRUCTIONS FOR USE
8 TROUBLESHOOTING AND SOLVING
9 PRECAUTIONS
10 HAZARDOUS USE
11 DIMENSIONS AND TECHNICAL DRAWINGS
12 MAINTENANCE PROCEDURES
13 DISPOSAL
14 HOW TO ORDER SPARE PARTS
15 HANDLING AND TRANSPORT
16 WARRANTY
17 CONFORMITY DECLARATION
1 INTRODUCTION
The present user’s and maintenance manual refers to the electric steam generator “SIMBA mini”.
It is possible to receive the latest release from our Technical Commercial Department or by visiting our website
www.ghidini-gb.it. The present user’s and maintenance manual contains important information for the operator’s health
safeguard and safety.
This manual has to be read and kept in a safe place, in order to be always at the operator’s disposal in case of need.
Ghidini s.r.l. cannot be held liable for any damage to things or injury to persons caused by improper use of the machine in
contrast with these instructions.
Any possible modifications effected on the components of the machine or its different use without prior written
authorization by Ghidini s.r.l., relieve the latter of injury to persons and / or damages to things, voiding any warranty
bindings, as well.
2 GENERAL DESCRIPTION
The SIMBA MINI boiler produces steam, and must be connected to external electric and water supplies to operate.
Its use is simple and efficient thanks to its front control panel.
3 MACHINE IDENTIFICATION
On the left side of the boiler, a metal rating plate quotes the model, serial number, the year of construction and
electrical and pressure supply.
4 TECHNICAL FEATURES
TECHNICAL FEATURES
Electrical power supply
230V – 1Ph – 50/60 Hz
Boiler capacity
5 L
Maximum steam pressure
2,8 bar
Boiler power supply
1450 W
Iron power supply
800 W
Sound pressure level
< 70 dB(A)
Operating temperature
+ 5 ÷ + 80 C
Operating humidity
90 % max.
Storing temperature
-20 ÷ +50 °C
Net dimensions
270 x 380 x 110 mm.
Net weight
11 Kg
Gross dimensions (with packing)
400 x 300 x 400 mm.
Gross weight (with packing)
12 Kg
Net weight with trolley
18 Kg
Overall dimensions with trolley (with packing)
460 x 310 x 930 mm.
Gross weight with trolley (with packing)
20 Kg
WARNING: Check that the supplied voltage and pressure correspond to that indicated in the table above.
