B.6 Fuse Specification Chart
Smaller fuses than those shown in the table are permitted.
Line Fuse
Model
I (A)
Input
I (A)
Output
I (A) Bussmann P/N
VFD002E11A 6 1.6 15 JJN-15
VFD002E21A 4.9 1.6 10 JJN-10
VFD002E23A 1.9 1.6 5 JJN-6
VFD004E11A 9 2.5 20 JJN-20
VFD004E21A 6.5 2.5 15 JJN-15
VFD004E23A 2.7 2.5 5 JJN-6
VFD004E43A 1.9 1.5 5 JJS-6
VFD007E11A 18 4.2 30 JJN-30
VFD007E21A 9.7 4.2 20 JJN-20
VFD007E23A 5.1 4.2 10 JJN-10
VFD007E43A 3.2 2.5 5 JJS-6
VFD015E21A 15.7 7.5 30 JJN-30
VFD015E23A 9 7.5 20 JJN-20
VFD015E43A 4.3 4.2 10 JJS-10
VFD022E21A 24 11 50 JJN-50
VFD022E23A 15 11 30 JJN-30
VFD022E43A 7.1 5.5 15 JJS-15
VFD037E23A 20.6 17 40 JJN-40
VFD037E43A 11.2 8.2 20 JJS-20
VFD055E23A 26 25 50 JJN-50
VFD055E43A 14 13 30 JJS-30
VFD075E23A 34 33 60 JJN-60
VFD075E43A 19 18 40 JJS-40
VFD110E43A 26 24 50 JJS-50
