Appendix D How to Use PLC Function
VFD-E Series
D-16 Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03
D.6.2 Device Reference Table
Device X
ID 0 1 2 3 4 5 6 7 10 11 12 13 14 15
Terminals of AC
Drives
MI1 MI2 MI3 MI4 MI5 MI6 -- -- -- -- -- -- -- --
Relay Card-2C
(EME-DR2CA)
-- -- -- -- -- -- -- -- -- -- -- -- -- --
Relay Card-3A (EME-
R3AA)
-- -- -- -- -- -- -- -- -- -- -- -- -- --
3IN/3OUT Card
(EME-D33A)
-- -- -- -- -- -- MI7 MI8 MI9 -- -- -- -- --
Device Y
ID 0 1 2 3 4 5 6 7 10 11 12 13 14 15
Terminals of AC
Drives
RY
MO1 -- -- -- -- -- -- -- -- -- -- -- --
Relay Card-2C
(EME-DR2CA)
-- --
RY2 RY3 --
-- -- -- -- -- -- -- -- --
Relay Card-3A (EME-
R3AA)
-- --
RY2 RY3 RY4
-- -- -- -- -- -- -- -- --
3IN/3OUT Card
(EME-D33A)
-- -- MO2 MO3 MO4 -- -- -- -- -- -- -- -- --
D.6.3 Devices Functions
The Function of Input/output Contacts
The function of input contact X: input contact X reads input signal and enter PLC by
connecting with input equipment. It is unlimited usage times for A contact or B contact of
each input contact X in program. The On/Off of input contact X can be changed with the
On/Off of input equipment but can’t be changed by using peripheral equipment (WPLSoft).
The Function of Output Contact Y
The mission of output contact Y is to drive the load that connects to output contact Y by
sending On/Off signal. There are two kinds of output contact: one is relay and the other is
transistor. It is unlimited usage times for A or B contact of each output contact Y in program.
But there is number for output coil Y and it is recommended to use one time in program.
Otherwise, the output result will be decided by the circuit of last output Y with PLC program
scan method.
