Appendix D How to Use PLC Function
VFD-E Series
Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03 D-25
D.7.2 Output Commands
Commands Function Operands
OUT Drive coil Y, M
SET Action latched (ON) Y, M
RST Clear the contacts or the registers Y, M, T, C, D
D.7.3 Timer and Counters
Commands Function Operands
TMR 16-bit timer T-K or T-D
CNT 16-bit counter C-K or C-D
D.7.4 Main Control Commands
Commands Function Operands
MC
Connect the common series connection
contacts
N0~N7
MCR
Disconnect the common series connection
contacts
N0~N7
D.7.5 Rising-edge/falling-edge Detection Commands of Contact
Commands Function Operands
LDP Rising-edge detection operation starts
X, Y, M, T, C
LDF Falling-edge detection operation starts
X, Y, M, T, C
ANDP Rising-edge detection series connection
X, Y, M, T, C
ANDF Falling-edge detection series connection
X, Y, M, T, C
ORP Rising-edge detection parallel connection
X, Y, M, T, C
ORF Falling-edge detection parallel connection
X, Y, M, T, C
