Appendix D How to Use PLC Function
_
VFD-E Series
D-26 Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03
D.7.6 Rising-edge/falling-edge Output Commands
Commands Function Operands
PLS Rising-edge output Y, M
PLF Falling-edge output Y, M
D.7.7 End Command
Command Function Operands
END Program end none
D.7.8 Description of the Application Commands
Mnemonic
CodesClassification
16 bits
P
Command
Function
CMP
3
Compare
ZCP
3
Zone compare
MOV
3
Data Move
Transmission
Comparison
BMOV
3
Block move
ADD
3
Perform the addition of BIN data
SUB
3
Perform the subtraction of BIN data
MUL
3
Perform the multiplication of BIN data
DIV
3
Perform the division of BIN data
INC
3
Perform the addition of 1
Four
Fundamental
Operations
of Arithmetic
DEC
3
Perform the subtraction of 1
ROR
3
Rotate to the right Rotation and
Displacement
ROL
3
Rotate to the left
DHSCS X High speed counter enable
FPID
3
Control PID parameters of inverter
FREQ
3
Control frequency of inverter
RPR
3
Read the parameter
Special
WPR
3
Write the parameter
D.7.9 Explanation for the Commands
Mnemonic Function
LD Load A contact
X0~X17 Y0~Y17 M0~M159 T0~15 C0~C7 D0~D29 X0~X17
Operand
999999
--
