Chapter 5 Parameters
_
VFD-E Series
5-2 Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03
5.1 Summary of Parameter Settings
a: The parameter can be set during operation.
Group 0 User Parameters
Parameter Explanation Settings
Factory
Setting
Customer
00.00 Identity Code of the
AC motor drive
Read-only ##
00.01 Rated Current
Display of the AC
motor drive
Read-only #.#
1: All parameters are read only
6: Clear PLC program
9: All parameters are reset to factory settings
(50Hz, 230V/400V or 220V/380V depends
on Pr.00.12)
00.02 Parameter Reset
10: All parameters are reset to factory
settings (60Hz, 220V/440V)
0
0: Display the frequency command value
(Fxxx)
1: Display the actual output frequency (Hxxx)
2: Display the content of user-defined unit
(Uxxx)
3: Multifunction display, see Pr.00.04
4: FWD/REV command
a00.03
Start-up Display
Selection
5: PLCx (PLC selections: PLC0/PLC1/PLC2)
0
0: Display the content of user-defined unit
(Uxxx)
1: Display the counter value (c)
2: Display PLC D1043 value (C)
3: Display DC-BUS voltage (u)
4: Display output voltage (E)
5: Display PID analog feedback signal value
(b) (%)
6: Output power factor angle (n)
7: Display output power (P)
8: Display the estimated value of torque as it
relates to current (t)
9: Display AVI (I) (V)
10: Display ACI / AVI2 (i) (mA/V)
a00.04
Content of Multi-
function Display
11: Display the temperature of IGBT (h) (¡C)
0
a00.05
User-Defined
Coefficient K
0. 1 to 160.0 1.0
00.06 Power Board
Software Version
Read-only #.##
00.07 Control Board
Software Version
Read-only #.##
00.08 Password Input 0 to 9999 0
00.09 Password Set 0 to 9999 0
00.10 Control Method 0: V/f Control 0
