Chapter 5 Parameters
_
VFD-E Series
Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03 5-3
Parameter Explanation Settings
Factory
Setting
Customer
1: Vector Control
00.11 Reserved
00.12
50Hz Base Voltage
Selection
0: 230V/400V
1: 220V/380V
0
Group 1 Basic Parameters
Parameter Explanation Settings
Factory
Setting
Customer
01.00
Maximum Output
Frequency (Fmax)
50.00 to 600.0 Hz 60.00
01.01
Maximum Voltage
Frequency (Fbase)
0.10 to 600.0 Hz 60.00
115V/230V series: 0.1V to 255.0V 220.0
01.02
Maximum Output
Voltage (Vmax)
460V series: 0.1V to 510.0V 440.0
01.03
Mid-Point Frequency
(Fmid)
0.10 to 600.0 Hz 1.50
115V/230V series: 0.1V to 255.0V 10.0
01.04
Mid-Point Voltage
(Vmid)
460V series: 0.1V to 510.0V 20.0
01.05
Minimum Output
Frequency (Fmin)
0.10 to 600.0 Hz 1.50
115V/230V series: 0.1V to 255.0V 10.0
01.06
Minimum Output
Voltage (Vmin)
460V series: 0.1V to 510.0V 20.0
01.07
Output Frequency
Upper Limit
0.1 to 120.0%
110.0
01.08
Output Frequency
Lower Limit
0.0 to100.0 %
0.0
a01.09 Accel Time 1 0.1 to 600.0 / 0.01 to 600.0 sec 10.0
a01.10 Decel Time 1 0.1 to 600.0 / 0.01 to 600.0 sec 10.0
a01.11 Accel Time 2 0.1 to 600.0 / 0.01 to 600.0 sec 10.0
a01.12 Decel Time 2 0.1 to 600.0 / 0.01 to 600.0 sec 10.0
a01.13 Jog Acceleration
Time
0.1 to 600.0 / 0.01 to 600.0 sec
10.0
a01.14 Jog Deceleration
Time
0.1 to 600.0 / 0.01 to 600.0 sec
10.0
a01.15 Jog Frequency 0.10 Hz to Fmax (Pr.01.00) Hz 6.00
0: Linear Accel/Decel
1: Auto Accel, Linear Decel
2: Linear Accel, Auto Decel
3: Auto Accel/Decel (Set by load)
01.16
Auto acceleration /
deceleration (refer to
Accel/Decel time
setting)
4: Auto Accel/Decel (set by Accel/Decel Time
setting)
0
01.17
Acceleration S-
Curve
0.0 to 10.0 / 0.00 to 10.00 sec 0.0
01.18
Deceleration S-
Curve
0.0 to 10.0 / 0.00 to 10.00 sec 0.0
0: Unit: 0.1 sec
01.19
Accel/Decel Time
Unit
1: Unit: 0.01 sec
0
