Chapter 5 Parameters
VFD-E Series
5-8 Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03
Parameter Explanation Settings
Factory
Setting
Customer
12: Counter Trigger Signal
13: Counter reset
14: E.F. External Fault Input
15: PID function disabled
16: Output shutoff stop
17: Parameter lock enable
18: Operation command selection (external
terminals)
19: Operation command selection(keypad)
20: Operation command
selection(communication)
21: FWD/REV command
22: Source of second frequency command
23: Run/Stop PLC Program (PLC1)
24: Download/execute/monitor PLC Program
(PLC2)
04.09
Multi-function Input
Contact Selection
Bit0:MI1
Bit1:MI2
Bit2:MI3
Bit3:MI4
Bit4:MI5
Bit5:MI6
Bit6:MI7
Bit7:MI8
Bit8:MI9
Bit9:MI10
Bit10:MI11
Bit11:MI12
0:N.O., 1:N.C.
P.S.:MI1 to MI3 will be invalid when it is 3-
wire control.
0
04.10
Digital Terminal
Input Debouncing
Time
1 to 20 (*2ms) 1
04.11
Min AVI Voltage
0.0 to 10.0V 0.0
04.12
Min AVI Frequency
0.0 to 100.0% 0.0
04.13
Max AVI Voltage
0.0 to 10.0V 10.0
04.14
Max AVI Frequency
0.0 to 100.0% 100.0
04.15
Min ACI Voltage
0.0 to 20.0mA 4.0
04.16
Min ACI Frequency
0.0 to 100.0%
0.0
04.17
Min ACI Voltage
0.0 to 20.0mA 20.0
04.18
Max ACI Frequency
0.0 to 100.0% 100.0
0: ACI
04.19 ACI/AVI2 Selection
1: AVI2
0
04.20
Min AVI2 Voltage
0.0 to 10.0V 0.0
