Chapter 5 Parameters
_
VFD-E Series
Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03 5-9
Parameter Explanation Settings
Factory
Setting
Customer
04.21
Min AVI2 Frequency
0.0 to 100.0%
0.0
04.22
Max AVI2 Voltage
0.0 to 10.0V 10.0
04.23
Max AVI2
Frequency
0.0 to 100.0% 100.0
Read only.
Bit0=1:MI1 used by PLC
Bit1=1:MI2 used by PLC
Bit2=1:MI3 used by PLC
Bit3=1:MI4 used by PLC
Bit4=1:MI5 used by PLC
Bit5=1:MI6 used by PLC
Bit6=1: MI7 used by PLC
Bit7=1: MI8 used by PLC
Bit8=1: MI9 used by PLC
Bit9=1: MI10 used by PLC
Bit10=1: MI11 used by PLC
04.24
The Digital Input
Used by PLC
Bit11=1: MI12 used by PLC
##
Read only.
Bit0=1:AVI used by PLC
04.25
The Analog Input
Used by PLC
Bit1=1:ACI/AVI2 used by PLC
##
Read only.
Bit0: MI1 Status
Bit1: MI2 Status
Bit2: MI3 Status
Bit3: MI4 Status
Bit4: MI5 Status
Bit5: MI6 Status
Bit6: MI7 Status
Bit7: MI8 Status
Bit8: MI9 Status
Bit9: MI10 Status
Bit10: MI11 Status
04.26
Display the Status of
Multi-function Input
Terminal
Bit11: MI12 Status
##
04.27
Internal/External
Multi-function Input
Terminals Selection
0~4095
0
04.28
Internal Terminal
Status
0~4095
0
Group 5 Multi-Step Speed and PLC Parameters
Parameter Explanation Settings
Factory
Setting
Customer
a05.00 1
st
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
