Ghisalba VFD-E Series - Page 55

Chapter 5 Parameters
_
VFD-E Series
5-10 Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03
Parameter Explanation Settings
Factory
Setting
Customer
a05.01 2
nd
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.02 3
rd
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.03 4
th
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.04 5
th
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.05 6
th
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.06 7
th
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.07 8
th
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.08 9
th
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.09 10
th
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.10 11
th
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.11 12
th
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.12 13
th
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.13 14
th
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.14 15
th
Step Speed
Frequency
0.00 to 600.0 Hz 0.00
Group 6 Protection Parameters
Parameter Explanation Settings
Factory
Setting
Custome
r
115/230V series: 330.0V to 410.0V 390.0V
460V series: 660.0V to 820.0V 780.0V
06.00
Over-Voltage Stall
Prevention
0.0: Disable over-voltage stall prevention
06.01
Over-Current Stall
Prevention during
Accel
0:Disable
20 to 250%
170
06.02
Over-Current Stall
Prevention during
Operation
0:Disable
20 to 250%
170
0: Disabled
1: Enabled during constant speed operation.
After the over-torque is detected, keep
running until OL1 or OL occurs.
06.03
Over-Torque
Detection Mode
(OL2)
2: Enabled during constant speed operation.
After the over-torque is detected, stop
running.
0
