Chapter 5 Parameters
_
VFD-E Series
5-12 Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03
Parameter Explanation Settings
Factory
Setting
Custome
r
26: W-phase error (cF3.2)
27: DCBUS error (cF3.3)
28: IGBT Overheat (cF3.4)
29: Power Board Overheat (cF3.5)
30: Control Board CPU WRITE failure (cF1.1)
31: Control Board CPU WRITE failure (cF2.1)
32: ACI signal error (AErr)
33: Reserved
34: Motor PTC overheat protection (PtC1)
35-39: Reserved
40: Communication time-out error of control
board and power board (CP10)
Group 7 Motor Parameters
Parameter Explanation Settings
Factory
Setting
Custome
r
a07.00 Motor Rated Current 30 %FLA to 120% FLA 100
a07.01
Motor No-Load
Current
0%FLA to 99% FLA 40
a07.02
Torque
Compensation
0.0 to 10.0 0.0
a07.03 Slip Compensation
(Used without PG)
0.00 to 10.00 0.00
07.04
Motor Parameters
Auto Tuning
0: Disable
1: Auto tuning R1
2: Auto tuning R1 + no-load test
0
07.05
Motor Line-to-line
Resistance R1
0~65535 m˖
0
07.06 Motor Rated Slip 0.00 to 20.00 Hz 3.00
07.07
Slip Compensation
Limit
0 to 250% 200
07.08
Torque
Compensation Time
Constant
0.01 ~10.00 Sec 0.10
07.09
Slip Compensation
Time Constant
0.05 ~10.00 sec 0.20
07.10
Accumulative Motor
Operation Time
(Min.)
0 to 1439 Min. 0
07.11
Accumulative Motor
Operation Time
(Day)
0 to 65535 Day 0
07.12
Motor PTC Overheat
Protection
0: Disable
1: Enable
0
07.13
Input Debouncing
Time of the PTC
Protection
0~9999(*2ms) 100
