Chapter 5 Parameters
_
VFD-E Series
Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03 5-13
Parameter Explanation Settings
Factory
Setting
Custome
r
07.14
Motor PTC Overheat
Protection Level
0.1~10.0V 2.4
07.15
Motor PTC Overheat
Warning Level
0.1~10.0V 1.2
07.16
Motor PTC Overheat
Reset Gh Level
0.1~5.0V 0.6
07.17
Treatment of the
Motor PTC Overheat
0: Warn and RAMP to stop
1: Warn and COAST to stop
2: Warn and keep running
0
Group 8 Special Parameters
Parameter Explanation Settings
Factory
Setting
Custome
r
08.00
DC Braking Current
Level
0 to 100% 0
08.01
DC Braking Time
during Start-Up
0.0 to 60.0 sec 0.0
08.02
DC Braking Time
during Stopping
0.0 to 60.0 sec 0.0
08.03
Start-Point for DC
Braking
0.00 to 600.0Hz 0.00
0: Operation stops after momentary power
loss
1: Operation continues after momentary
power loss, speed search starts with the
Master Frequency reference value
08.04
Momentary Power
Loss Operation
Selection
2: Operation continues after momentary
power loss, speed search starts with the
minimum frequency
0
08.05
Maximum Allowable
Power Loss Time
0.1 to 5.0 sec 2.0
0: Disable speed search
1: Speed search starts with last frequency
command
08.06
Base-block Speed
Search
2: Starts with minimum output frequency
1
08.07
B.B. Time for Speed
Search
0.1 to 5.0 sec 0.5
08.08
Current Limit for
Speed Search
30 to 200% 150
08.09
Skip Frequency 1
Upper Limit
0.00 to 600.0 Hz 0.00
08.10
Skip Frequency 1
Lower Limit
0.00 to 600.0 Hz 0.00
08.11
Skip Frequency 2
Upper Limit
0.00 to 600.0 Hz 0.00
08.12
Skip Frequency 2
Lower Limit
0.00 to 600.0 Hz 0.00
08.13
Skip Frequency 3
Upper Limit
0.00 to 600.0 Hz 0.00
