Chapter 5 Parameters
_
VFD-E Series
5-14 Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03
Parameter Explanation Settings
Factory
Setting
Custome
r
08.14
Skip Frequency 3
Lower Limit
0.00 to 600.0 Hz 0.00
08.15 Auto Restart After
Fault
0 to 10 (0=disable) 0
08.16
Auto Reset Time at
Restart after Fault
0.1 to 6000 sec
60.0
0: Disable
08.17 Auto Energy Saving
1: Enable
0
0: AVR function enable
1: AVR function disable
2: AVR function disable for decel.
08.18 AVR Function
3: AVR function disable for stop
0
115V / 230V series: 370.0to 430.0V
380.0
08.19
Software Braking
Level
460V series: 740.0 to 860.0V
760.0
a08.20
Compensation
Coefficient for Motor
Instability
0.0~5.0
0.0
Group 9 Communication Parameters
Parameter Explanation Settings
Factory
Setting
Custome
r
09.00
Communication
Address
1 to 254 1
0: Baud rate 4800bps
1: Baud rate 9600bps
2: Baud rate 19200bps
09.01 Transmission Speed
3: Baud rate 38400bps
1
0: Warn and keep operating
1: Warn and ramp to stop
2: Warn and coast to stop
09.02
Transmission Fault
Treatment
3: No warning and keep operating
3
09.03 Time-out Detection
0.1 ~ 120.0 seconds
0.0: Disable
0.0
0: 7,N,2 (Modbus, ASCII)
1: 7,E,1 (Modbus, ASCII)
2: 7,O,1 (Modbus, ASCII)
3: 8,N,2 (Modbus, RTU)
4: 8,E,1 (Modbus, RTU)
09.04
Communication
Protocol
5: 8,O,1 (Modbus, RTU)
0
09.05 Reserved
09.06 Reserved
09.07
Response Delay
Time
0 ~ 200 (unit: 2ms)
1
